| Brand | : | V-Sol |
| Jenis | : | FTTH OLT |
| Kode | : | V1600GS-F |
| Harga | : | Rp 2.400.000,00 |
V1600GS-F vsol is a box-type GPON OLT with one PON port. The price of V1600GS-F is very attractive and the performance is very strong. The splitting ratio of its PON port is 1:128, and the farthest transmission distance is 20KM. Its uplink and downlink bandwidth is as high as: 1.25Gbps/2.5Gbps. V1600GS-F can be widely used in FTTH, SOHO, small business office and other application scenarios.
1*GPON, 2*RJ45+1*SFP/SFP+.
*Sudah termasuk 1x SFP 8dBm
Specification
| Model | V1600GS-F |
| Uplink Port | QTY : 3 |
| RJ45(1G) : 2 | |
| SFP(1G)/SFP+(10G) : 1 | |
| GPON Port | QTY : 1 |
| Fiber Type : 9/125μm SM | |
| Connector : SC/UPC, Class C++/C+++ Class C++ : TX>6.5dBm, Sen: -32dBm Class C+++ : TX>7.5dBm, Sen: -33dBm | |
| GPON port speed Upstream : 1.244Gbps Downstream : 2.488Gbps | |
| Wavelength TX : 1490nm RX : 1310nm | |
| Max splitting ratio : 1:128 | |
| Transmission Distance : 20KM | |
| Management Port | 1*USB-COM(Type-C) port |
| Backplane Bandwidth (Gbps) | 16 |
| Port Forwarding Rate(Mpps) | 23.808 |
| Management Mode | WEB/Telnet/CLI/SNMP |
| Lightning Protection Level | Power supply : 4KV Device Interface : 1KV |
| Power supply | AC : Working Voltage Range: 100~240V, Rated Voltage: 110V/220V DC : 12V/2A |
| Working temperature | -20 ~ +60 C |
| Storage temperature | -40 ~ +70 C |
| Relative Humidity | 5 ~ 95% (Non-condensing) |
| Dimension (L*W*H) | 210 x 173 x 43.6 mm |
